Nominal data
Type	R2E175-RA52-01
Motor	M2E052-CA
Phase		1~	1~
Nominal voltage	VAC	230	230
Frequency	Hz	50	60
Valid for approval/standard		CE	CE
Speed	min-1	2450	2700
Power input	W	46	57
Current draw	A	0.21	0.25
Capacitance	µF	1.5	1.5
Min. ambient temperature	°C	-25	-25
Max. ambient temperature	°C	60	70
Starting current	A	0.32	0.34
ml = max. load · me = max. efficiency · fa = running at free air · cs = customer specs · cu = customer unit

R2E175-RA52-01 Ebmpapst fan For Electronic equipment, cabinet and case

Ebm fan is widely used，whether it is automobile, railway, electronic products, medical treatment, or household, ventilation, air conditioning, refrigeration system, EBM fans are everywhere. The centrifugal fans are also used in applications such as central air conditioning units or building ventilation systems. As an authorized agent of ebm,henry is familiar with fan technology. We only provide new and authentic fans for our customers, and strive to set a model for the global fan industry.

Henry also offers other ebmpapst fans，the models are as follows：

R3G190-RB01-01

R3G190-RD45-01

R3G190-RC05-03

R3G190-RG19-01

R3G190-RD45-03

K3G190-RB01-01

K3G190-RD45-01

K3G190-RC05-03

K3G190-RD45-03

R3G220-RC50-01

R3G220-RD53-01

R3G220-RC05-03

R3G220-RG19-01

R3G220-RD53-03

K3G220-RC05-01

K3G220-RD53-01

K3G220-RC05-03
