ebm-papst W3G910-KS35-03 F01 910mm 230V AC Axial Refrigerator Fan
Brand：ebm-papst (100% Genuine)
Model：W3G910-KS35-03 F01
Category：EC Axial Fan
Description： 100% genuine 230VAC EC axial fan, 1100 RPM, 2100W, up to 29145 m³/h airflow. In stock, fast delivery. Ideal for HVAC, cooling towers, and industrial ventilation.
- Specification
- Details
- Application
|
Type |
W3G910-KS35-03/F01 |
|
|
Motor |
M3G150-FF |
|
|
Phase |
|
3 ~ |
|
Nominal voltage |
VAC |
400V |
|
Frequency |
Hz |
50/60 |
|
Method of obtaining data |
|
ml |
|
Speed(rpm) |
min-1 |
850 |
|
Power consumption |
W |
1770 |
|
Current draw |
A |
2.8 |
|
Min. ambient temperature |
°C |
-25 |
|
Max. ambient temperature |
°C |
60 |
|
Max. back pressure |
Pa |
185 |
|
ml=max. load； me=max. efficiency； fa=free air; cs = customer specification； ce = customer equipment |
||
High-Performance EC Axial Fan for HVAC & Industrial Ventilation
The W3G910-KS35-03/F01 is an original ebm-papst EC axial fan designed for high-volume airflow in HVAC and industrial ventilation applications. Operating at 3~ 400 VAC with a maximum speed of 850 rpm, it delivers powerful airflow up to 29145 m³/h, ensuring efficient air movement in large-scale systems.
With advanced EC motor technology, this fan provides high energy efficiency, stable performance, and precise speed control via 0–10V or PWM signals. Its IP54 protection and wide operating temperature range (-25°C to +60°C) make it suitable for demanding environments.
Available from stock with fast global delivery, the W3G910-KS35-03/F01 ensures original ebm-papst quality and long service life. Professional technical support is available for selection, system integration, and replacement support.
Product Details
（If you need more installation pictures or detailed technical PDF documents of ebm-papst S4E450 8317078900, please feel free to contact us at any time.）
 |
 |
Why choose us ?► Large quantity of multi brand fans in stock supply
In factories and production facilities, this fan delivers strong airflow and reliable operation. It is suitable for continuous-duty ventilation where durability and efficiency are critical.
Frequently Asked QuestionsQ1: What applications is W3G910-KS35-03/F01 used for?
