W1G200-EA91-70
Brand：ebmpapst
Model：W1G200-EA91-70
Category：Axial fans
Description：
Sales Hotline:+86 10-62547612
Cell Phone:+86 187 0152 6587
E-mail: Jason@bjhengrui.cn / qin@bjhengrui.cn / sales06@bjhengrui.cn
- Specification
- Details
- Application
| Technical description | |
|---|---|
| Weight | 1 kg |
| Motor size | 55 |
| Size | 200 mm |
| Rotor surface | Painted black |
| Blade material | Sheet steel, painted black |
| Fan housing material | PP plastic |
| Number of blades | 5 |
| Airflow direction | V |
| Direction of rotation | Counterclockwise, viewed toward rotor |
| Degree of protection | IP54 |
| Insulation class | "B" |
| Moisture (F) / Environmental (H) protection class | H1+ |
| Max. permitted ambient temp. for motor (transport/storage) | +80 °C |
| Min. permitted ambient temp. for motor (transport/storage) | - 40 °C |
| Installation position | Any |
| Condensation drainage holes | None |
| Mode | S1 |
| Motor bearing | Ball bearing |
| Technical features | - Speed selection max./min. - Soft start - Thermal overload protection for motor |
| Speed levels | 2 |
| EMC immunity to interference | According to EN 61000-6-2 (industrial environment) |
| EMC circuit feedback | According to EN 61000-3-2/3 |
| EMC interference emission | According to EN 61000-6-3 (household environment) |
| Touch current according to IEC 60990 (measuring circuit Fig. 4, TN system) | <= 0,25 mA |
| Electrical hookup | Plug |
| Motor protection | Thermal overload protector (TOP) internally connected |
| with cable | Lateral |
| Protection class | II |
| Approval | CSA C22.2 No. 77 / UL 1004-3 |
